MODEL-NO	Size				Hot zone Surtace Area	*NoMinal Nading Aaiues
	Diameter	Hot zone Length	Cold End Length	Overall Length	Hot zone Surtace Area	*NoMinal Nading Aaiues
	mm	mm	mm	mm	cm²	Volts	Watts	Ohms
BBS08 - a b c d	8	100 150 200 250	100 100 100 100	300 350 400 450	25 38 50 63	35 50 65 80	430 650 850 1070	2.8 3.8 5.0 6.0
BBS10 - a b c d	10	100 150 200 250	150 150 150 150	400 450 500 550	31 47 63 79	30 45 60 75	530 800 1080 1340	1.7 2.5 3.4 4.2
BBS12 - a b c d e f g h i j k	12	150 150 200 200 200 250 250 250 300 300 300	100 150 100 150 200 100 150 200 100 150 200	350 450 400 500 600 450 550 650 500 600 700	56 56 75 75 75 94 94 94 113 113 113	40 40 55 55 55 70 70 70 80 80 80	900 900 1200 1200 1200 1500 1500 1500 1800 1800 1800	1.8 1.8 2.5 2.5 2.5 3.3 3.3 3.3 3.6 3.6 3.6
BBS14 - a b c d e f g	14	200 250 250 300 300 350 400	200 200 250 350 375 200 250	600 650 750 1000 1050 750 900	88 110 110 132 132 154 176	50 60 60 70 70 85 100	1400 1750 1750 2100 2100 2450 2800	1.8 2.1 2.1 2.3 2.3 3.0 3.6
BBS16 - a b c d e f	16	300 300 400 450 500 600	200 375 250 250 250 250	700 1050 900 950 1000 1100	150 150 200 225 250 300	70 70 95 110 120 140	2400 2400 3260 3600 4000 4800	2.0 2.0 2.8 3.3 3.6 4.1
BBS20 - a b c d e f g h i j k l m n	20	300 300 400 400 500 500 600 600 700 700 800 800 900 1000	250 350 250 300 300 400 300 400 300 400 300 400 300 300	800 1000 900 1000 1100 1300 1200 1400 1300 1500 1400 1600 1500 1600	188 188 251 251 314 314 376 376 439 439 502 502 565 627	65 65 85 85 110 110 130 130 150 150 170 170 190 210	3000 3000 4000 4000 5000 5000 6000 6000 7000 7000 8000 8000 9000 10000	1.4 1.4 1.8 1.8 2.4 2.4 2.8 2.8 3.2 3.2 3.6 3.6 4.0 4.4
BBS25 - a b c d e f g h i j k l m n o p q	25	300 400 400 500 500 600 600 700 700 800 800 900 1000 1100 1200 1300 1400	300 300 400 300 400 300 400 300 400 300 400 300 300 300 300 300 300	900 1000 1200 1100 1300 1200 1400 1300 1500 1400 1600 1500 1600 1700 1800 1900 2000	236 314 314 392 392 470 470 550 550 627 627 705 785 962 940 1020 1095	55 75 75 90 90 110 110 130 130 150 150 170 190 200 220 230 250	3600 4700 4700 5800 5800 7000 7000 8200 8200 7400 7400 10600 11800 13000 14000 15300 16500	0.9 1.2 1.2 1.4 1.4 1.7 1.7 2.1 1.1 2.4 2.4 2.7 3.1 3.1 3.5 3.5 3.8
